SPECIFICATION |
|
|
Laser wave-length 1064 ± 4 nm |
Laser wave-length 1064 ± 4 nm |
|
Laser beam quality M < 1.7 |
Laser beam quality M < 1.7 |
|
Average output power 20 W |
Average output power 20 W |
|
Frequency range 30 - 60 kHz |
Frequency range 30 - 60 kHz |
|
Energy per pulse 0.8 - 1.0 mJ |
Energy per pulse 0.8 - 1.0 mJ |
|
Pulse width 80 - 140 ns |
Pulse width 80 - 140 ns |
|
Power tunable range 5 - 100 % |
Power tunable range 5 - 100 % |
|
Output Fiber length 1.5 m |
Output Fiber length 1.5 m |
|
Marking depth 0.2 mm |
Marking depth 0.2 mm |
|
Repetition accuracy 1 um |
Repetition accuracy 1 um |
|
Min. line width 0.01 mm |
Min. line width 0.01 mm |
|
Min. size 0.2 mm |
Min. size 0.2 mm |
|
Max. marking speed 6,000 mm/s |
Max. marking speed 6,000 mm/s |
|
Power input AC 220 v / 50hz |
Power input AC 220 v / 50hz |
|
Cooling system Air Cool |
Cooling system Air Cool |
|
Laser lifetime 100,000 hours |
Laser lifetime 100,000 hours |
|
Software system English |
Software system English |
|
Laser source MaxPhotonics |
Laser source MaxPhotonics |
|
Laser Galvanometer head China |
Laser Galvanometer head China |
|
Scanner head size 94*96*112 |
Scanner head size 94*96*112 |
|
Working area 110*110*100 mm. |
Working area 110*110*100 mm. |
|
Focus distance 160 mm |
Focus distance 160 mm |
